NASA’s Curiosity rover uses smartphone technology to reveal the geology of Mars

A selfie taken by NASA’s Curiosity Mars rover on Sol 2291 (January 15) at the “Rock Hall” drill site, located on Vera Rubin Ridge. (NASA/JPL-Caltech)
Spread the love

Curiosity has used devices found in smartphones to measure slight variations in gravitational fields refining the understanding of how Gale crater and the mountain at its centre were formed.

Clever use of non-science engineering data from NASA’s Mars rover Curiosity has let a team of researchers, including an Arizona State University graduate student, measure the density of rock layers in 96-mile-wide Gale Crater.

The gravitational field sensed by the rover as it traversed across the Martian crater’s dusty basin indicates that the underlying sedimentary material is relatively porous, disproving a theory that the crater floor was once buried beneath several kilometres of rock. The findings are due to be published in the on February 1st in the Journal Science.

Travis Gabriel, a graduate student in ASU’s School of Earth and Space Exploration who worked on computing what the grain density should be for the rocks and ancient lakebed sediments the rover has been driving over, says: “What we were able to do is measure the bulk density of the material in Gale Crater.”

“Working from the rocks’ mineral abundances as determined by the Chemistry and Mineralogy instrument, we estimated a grain density of 2810 kilograms per cubic meter.”

He continues: “However the bulk density that came out of our study is a lot less — 1680 kilograms per cubic meter.”

The much lower figure shows that the rocks have a reduced density most likely resulting from the rocks being more porous. This means the rocks have been compressed less than scientists have thought.

Since making planetfall in 2012, the Curiosity rover has been exploring the complex landscapes within Gale crater, a dry ancient lakebed. The rover has also been exploring the area surrounding Aeolis Mons (Mount Sharp), the 5-kilometre-tall mountain that forms a central peak in Gale crater.

The above image shows Curiosity’s landing site in the yellow ring. Mount Sharp is the large central peak (NASA)

The above image shows Curiosity’s landing site in the yellow ring. Mount Sharp is the large central peak (NASA

The origin of Mount Sharp is hotly debated; since the peak’s summit is higher than much of the crater’s rim, some researchers have suggested that the crater was once filled with sediment and the current topography is a result of erosion. Others have argued that wind-blown sediments collected at the crater’s centre, slowly building the Mount Sharp to its current altitude.

Like a smartphone — but smarter.

Gravimetry, the precise measurement of tiny variations in gravitational fields, can be used to weigh mountains by detecting the density of subsurface materials. Orbital gravimetric surveys have been used to probe extra-terrestrial geology, but they lack the detail of the ground-based measurements available on Earth.

‘Well, we’re not turning back now!’ the Curiosity rover launch left behind its gravitational acceleration measurement tools (NASA)

‘Well, we’re not turning back now!’ the Curiosity rover launch left behind its gravitational acceleration measurement tools (NASA)

However, when Curiosity left for Mars, it left its gravitational acceleration measuring tools behind. Kevin Lewis of the John Hopkins University, the paper’s lead author, and his colleagues devised a way to recalibrate the rover inertial measurement units (RIMUs), a set of accelerometers used for routine navigation, to measure local changes to the gravitational field.

The RIMUs are much like those found in every smartphone determining its orientation and motion. Curiosity’s sensors do the same, but with much greater precision, helping engineers and mission controllers navigate the rover across the Martian surface.

But while the rover is standing still, the accelerometers can also measure the local force of gravity at that spot on Mars.

The team took the engineering data from the first five years of the mission — Curiosity landed in 2012 — and used it to measure the gravitational tug of Mars at more than 700 points along the rover’s track. As Curiosity has been ascending Mount Sharp, the mountain began to tug on it, as well — but not as much as scientists expected.

The new findings suggest Mount Sharp’s lower layers have been compacted by only a half-mile to a mile (1 to 2 kilometres) of material — much less than if the crater had been completely filled.

This reveals low-density porous rocks beneath the rover and as deep burial would have compacted the rocks to a higher density, this indicates that only a fraction of the crater was ever filled in the past. This adds support to the model that proposes Mount Sharp formed largely in its current form, as a free-standing mound within Gale.

Ashwin Vasavada, Curiosity’s project scientist at NASA’s Jet Propulsion Laboratory in Pasadena, California, which manages the mission, says: “There are still many questions about how Mount Sharp developed, but this paper adds an important piece to the puzzle.”

“I’m thrilled that creative scientists and engineers are still finding innovative ways to make new scientific discoveries with the rover.”

Curiosity is movin’ on

Shortly after taking the incredible selfie comprised of 57 different images (top of the page)with its Mars Hand Lens Imager (MAHLI) camera on the end of its robotic arm on January 15th, Curiosity moved from the twisting Vera Rubin Ridge, the rover’s home for more than a year, and descended toward a clay region of Mount Sharp.

Curiosity drills down to collect samples at ‘Rock hall’ (NASA)

Curiosity drills down to collect samples at ‘Rock Hall’ (NASA

On December 15th, Curiosity drilled its 19th sample at a location on the ridge called Rock Hall. The “Rock Hall” drill hole is visible to the lower left of the rover; the scene is dustier than usual at this time of year due to a regional dust storm.

Curiosity has been exploring the ridge since September of 2017. It’s now headed into the “clay-bearing unit,” which sits in a trough just south of the ridge. Clay minerals in this unit may hold more clues about the ancient lakes that helped form the lower levels on Mount Sharp.
